![[IMAGE] of](P_1x5R_069_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x5R_069_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 52 V |
| Operational Voltage 92 V |
Parts committed by Bolla Gino on date 11/19/2007
| Part | ID |
|---|---|
| BBM | BBM_069-1x5 |
| VHDI | 1x5R_543 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W52_D0LQC8T | 18A |
| ROC1 | W52_D0LQC8T | 17D |
| ROC2 | W52_D0LQC8T | 17A |
| ROC3 | W52_D0LQC8T | 16C |
| ROC4 | W52_D0LQC8T | 03C |
Inspected by Lockwood Gale on date 11/30/2007
| LR_dev | 0.046 |
| LL_dev | 0.039 |
PLAQUETTE GLUED with HALF PRESSURE
| FINAL COMMENT by Lockwood Gale | Force used to join BBM to VHDI = 2 kg per ROC. No assembly problems. No wirebonding problems. |
PLAQUETTE made READY for ENCAPSULATION on 11/30/2007 by Lockwood Gale
PLAQUETTE encapsulated on 12/4/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 12/4/2007 by Ozhan Koybasi
P_1x5R_069_Aon 12/5/2007 1:33 PM
P_1x5R_069_Aon 12/5/2007 1:33 PM
PLAQUETTE TESTED on 2007-12-05 by Ozhan Koybasi
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | |
| Ibias_DAC | 156 | 160 | 148 | 140 | 156 | |
| Vana | 149 | 154 | 156 | 138 | 147 | |
| Cal_Del | 91 | 80 | 90 | 92 | 79 | |
| Vthrs_Comp | 84 | 90 | 91 | 88 | 88 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | |
| Dead | 1 | 5 | 110 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 1 | 5 | 110 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x5R_069_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x5R_069_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x5R_069_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x5R_069_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x5R_069_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x5R_069_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 90 | 100 | 95 | 100 | 100 |
| Vsf | 150 | 150 | 155 | 140 | 145 |
| VoffsetOp | 105 | 125 | 130 | 95 | 110 |
| VIbias_PH | 100 | 100 | 100 | 100 | 110 |
Noise MAP at VMAX
![[IMAGE] of](P_1x5R_069_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x5R_069_A-580-efficiency.jpg)
Noise MAP at -200 V
![[IMAGE] of](P_1x5R_069_A-200-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x5R_069_A-200-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
