![[IMAGE] of](P_1x5R_046_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 550 V |
![[IMAGE] of](P_1x5R_046_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date 5/22/2007
| Part | ID |
|---|---|
| BBM | BBM_046-1x5 |
| VHDI | 1x5R_288 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W36_XD4K3LT | 06A |
| ROC1 | W36_XD4K3LT | 05D |
| ROC2 | W36_XD4K3LT | 04C |
| ROC3 | W36_XD4K3LT | 04B |
| ROC4 | W36_XD4K3LT | 04A |
Inspected by Lockwood Gale on date 6/6/2007
| LR_dev | 0.043 |
| LL_dev | 0.022 |
PLAQUETTE GLUED with FULL PRESSURE
| FINAL COMMENT by Lockwood Gale | No assembly problems. No wirebond problems. |
PLAQUETTE made READY for ENCAPSULATION on 6/6/2007 by Lockwood Gale
PLAQUETTE encapsulated on 6/6/2007 by Kozak Brian
PLAQUETTE made READY for testing on 6/6/2007 by Kozak Brian
P_1x5R_046_Aon 6/7/2007 12:28 PM
P_1x5R_046_A-1on 6/7/2007 12:35 PM
P_1x5R_046_A-1on 6/7/2007 12:35 PM
PLAQUETTE TESTED on 2007-06-07 by Emily Grace
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | |
| Ibias_DAC | 146 | 164 | 144 | 160 | 162 | |
| Vana | 125 | 142 | 117 | 129 | 140 | |
| Cal_Del | 97 | 89 | 93 | 83 | 89 | |
| Vthrs_Comp | 69 | 75 | 75 | 81 | 81 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x5R_046_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x5R_046_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x5R_046_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x5R_046_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x5R_046_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x5R_046_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 135 | 90 | 140 | 125 | 95 |
| Vsf | 140 | 140 | 140 | 140 | 145 |
| VoffsetOp | 60 | 80 | 65 | 100 | 90 |
| VIbias_PH | 100 | 100 | 95 | 100 | 100 |
Noise MAP at VMAX
![[IMAGE] of](P_1x5R_046_A-1-530-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x5R_046_A-1-530-efficiency.jpg)
Noise MAP at -200 V
![[IMAGE] of](P_1x5R_046_A-1-200-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x5R_046_A-1-200-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
