![[IMAGE] of](P_1x5R_042_C_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x5R_042_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 52 V |
| Operational Voltage 92 V |
Parts committed by Bolla Gino on date CCYY-MM-DD
| Part | ID |
|---|---|
| BBM | BBM_042-1x5 |
| VHDI | 1x5R_214 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XK4K3ET | 55D |
| ROC1 | XK4K3ET | 56D |
| ROC2 | XK4K3ET | 58C |
| ROC3 | XK4K3ET | 58B |
| ROC4 | XK4K3ET | 54C |
Inspected by Arndt Kirk on date 2006-08-24
| LR_dev | 0.000 |
| LL_dev | 0.031 |
| FINAL COMMENT by Arndt Kirk | No problem assembly. No wirebonding problem |
PLAQUETTE made READY for testing on 2006-08-24 by Arndt Kirk
PLAQUETTE TESTED on 2006-08-25 by Isaac Childres
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | |
| Ibias_DAC | 159 | 156 | 145 | 168 | 159 | |
| Vana | 129 | 133 | 144 | 137 | 135 | |
| Cal_Del | 90 | 75 | 100 | 70 | 79 | |
| Vthrs_Comp | 75 | 74 | 76 | 76 | 76 | |
| Unbumped | 0 | 1 | 0 | 2 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 1 | 0 | |
| Total BAD | 0 | 1 | 0 | 3 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x5R_042_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x5R_042_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x5R_042_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x5R_042_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x5R_042_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x5R_042_Cno-bump-light.jpg) |
LIGHT_XML-File |
PLAQUETTE READY FOR SHIPPING
Shipped on date 2006-08-30
