P_1x5R_036_C

Parts committed by Bolla Gino on date 1/3/2007

PartID
BBMBBM_036-1x5
VHDI1x5R_227

ROCROC waferLabel
ROC0XE4KFET61B
ROC1XE4KFET75D
ROC2XE4KFET63B
ROC3XE4KFET66C
ROC4XE4KFET67D

Inspected by Arndt Kirk on date 1/5/2007
LR_dev0.044
LL_dev0.023
FINAL COMMENT by Arndt KirkNo assembly problems. No wirebond problem.

PLAQUETTE made READY for testing on 1/5/2007 by Arndt Kirk

P_1x5R_036_Con 1/5/2007 3:37 PM

PLAQUETTE TESTED on 2007-01-05 by Gino Bolla

[IMAGE] of
IV_XML-File
Maximum Voltage 600 V
[IMAGE] of
LASER_XML-File
Depletion Voltage 54 V
Operational Voltage 94 V

ROCROC0ROC1ROC2ROC3ROC4
Ibias_DAC132134130120138
Vana109127120123131
Cal_Del82849810073
Vthrs_Comp7985677092
Unbumped10001
Dead00000
Noisy00000
Undecoded00000
Total BAD10001

ASSEMBLY_XML-File SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
[IMAGE] of I_BIAS_DAC_XML-File
[IMAGE] of VANA_XML-File
[IMAGE] of DEAD_XML-File
[IMAGE] of NOISY_XML-File
[IMAGE] of UNDECODED_XML-File
[IMAGE] of LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

PLAQUETTE encapsulated on 1/17/2007 by Arndt Kirk

P_1x5R_036_C-1on 1/17/2007 4:03 PM

P_1x5R_036_C-1on 1/17/2007 4:03 PM AFTER POTTING

[IMAGE] of

BAD CHANNELS COMPARISON Before/after ENCAPSULATION

ROCDEADNOISYUNDECODEDTESTDLIGHT
ROC00/00/00/01/21/2
ROC10/00/00/00/00/0
ROC20/00/00/00/00/0
ROC30/00/00/00/00/0
ROC40/00/00/01/11/1

DEVICE READY FOR SHIPPING

Shipped on date 2007-01-22

Plaquette assigned to panel P4L_030
