![[IMAGE] of](P_1x5L_132_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x5L_132_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 42 V |
| Operational Voltage 82 V |
Parts committed by Bolla Gino on date 5/22/2007
| Part | ID |
|---|---|
| BBM | BBM_132-1x5 |
| VHDI | 1x5L_602 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W45_D3LQFLT | 44B |
| ROC1 | W45_D3LQFLT | 44A |
| ROC2 | W45_D3LQFLT | 43C |
| ROC3 | W45_D3LQFLT | 43A |
| ROC4 | W45_D3LQFLT | 41B |
Inspected by Lockwood Gale on date 6/29/2007
| LR_dev | 0.102 |
| LL_dev | 0.073 |
PLAQUETTE GLUED with FULL PRESSURE
| FINAL COMMENT by Lockwood Gale | No assembly problems. No wirebonding problems. |
PLAQUETTE made READY for ENCAPSULATION on 6/29/2007 by Lockwood Gale
PLAQUETTE encapsulated on 7/2/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 7/2/2007 by Ozhan Koybasi
P_1x5L_132_Aon 7/3/2007 10:58 AM
P_1x5L_132_Aon 7/3/2007 10:58 AM
PLAQUETTE TESTED on 2007-07-03 by Emily Grace
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | |
| Ibias_DAC | 164 | 158 | 156 | 164 | 158 | |
| Vana | 134 | 140 | 141 | 134 | 158 | |
| Cal_Del | 79 | 74 | 78 | 82 | 83 | |
| Vthrs_Comp | 90 | 87 | 89 | 88 | 89 | |
| Unbumped | 0 | 0 | 0 | 0 | 0 | |
| Dead | 1 | 82 | 197 | 20 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 1 | 82 | 197 | 20 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x5L_132_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x5L_132_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x5L_132_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x5L_132_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x5L_132_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x5L_132_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 115 | 90 | 100 | 95 | 90 |
| Vsf | 140 | 145 | 145 | 140 | 150 |
| VoffsetOp | 90 | 100 | 110 | 120 | 100 |
| VIbias_PH | 100 | 100 | 100 | 100 | 100 |
Noise MAP at VMAX
![[IMAGE] of](P_1x5L_132_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x5L_132_A-580-efficiency.jpg)
Noise MAP at -200 V
![[IMAGE] of](P_1x5L_132_A-200-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x5L_132_A-200-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
