| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x5L_084_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 52 V |
| Operational Voltage 92 V |
Parts committed by Bolla Gino on date CCYY-MM-DD
| Part | ID |
|---|---|
| BBM | BBM_084-1x5 |
| VHDI | 1x5L_215 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XK4K3ET | 04B |
| ROC1 | XK4K3ET | 05A |
| ROC2 | XK4K3ET | 03C |
| ROC3 | XK4K3ET | 57B |
| ROC4 | XK4K3ET | 55C |
Inspected by Arndt Kirk on date 2006-08-23
| LR_dev | 0.055 |
| LL_dev | 0.068 |
| FINAL COMMENT by Arndt Kirk | No problem assembly. No wirebonding problem |
PLAQUETTE made READY for testing on 2006-08-23 by Arndt Kirk
PLAQUETTE TESTED on 2006-08-24 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | |
| Ibias_DAC | 156 | 147 | 143 | 140 | 142 | |
| Vana | 116 | 127 | 142 | 115 | 118 | |
| Cal_Del | 88 | 82 | 83 | 97 | 88 | |
| Vthrs_Comp | 78 | 77 | 75 | 70 | 72 | |
| Unbumped | 1 | 0 | 8 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 1 | |
| Total BAD | 1 | 0 | 8 | 0 | 1 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x5L_084_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x5L_084_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x5L_084_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x5L_084_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x5L_084_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x5L_084_Cno-bump-light.jpg) |
LIGHT_XML-File |
PLAQUETTE READY FOR SHIPPING
Shipped on date 2006-08-25
