P_1x2R_181_C-2

Production testing

Date:5/21/2007

Operator: Gino Bolla

start testing time:8:49 AM

Sensor: S_1x2R_18, Data for leakage current measurement , and plot on overall it is a GOOD sensor
ROCROC waferLabel
ROC0KBNG0QT49D
ROC1KBNG0QT28C

Depletion Voltage is -54 and suggested operational voltage is -94
Ibias_DAC, Ibias_DAC Data 146 154
Vana, VanaData 138 144
CalDelData and plots8970
VthrCompData and plots8386
TestDdata ,TestD Plots20
LightData ,Light Plots440
Pass/Fail TestD GOOD GOOD
Pass/Fail LIGHT BAD GOOD

Noise MAP at VMAX

[IMAGE] of

Efficiency MAP

[IMAGE] of

EXTRA DACs for NOISE

VHldDe8590
Vsf140145
VoffsetOp7595
VIbias_PH10595
ROC0 NOISE[IMAGE] of [IMAGE] of MEAN = 4.833042

SIGMA = 0.449673
ROC1 NOISE[IMAGE] of [IMAGE] of MEAN = 3.871205

SIGMA = 0.310272

Comment (if any):

This Device have been tested 2Times prior to this one and here are the links to the previous tests:

P_1x2R_181_C-1.html,

P_1x2R_181_C.html,

End testing time: 9:22 AM
