![[IMAGE] of](P_1x2R_142_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x2R_142_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 46 V |
| Operational Voltage 86 V |
Parts committed by Arndt Kirk on date 3/1/2007
| Part | ID |
|---|---|
| BBM | BBM_142-1x2T |
| VHDI | 1x2R_278 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W34_XA4K3PT | 38A |
| ROC1 | W34_XA4K3PT | 37D |
Inspected by Arndt Kirk on date 3/9/2007
| LR_dev | 0.070 |
| LL_dev | 0.053 |
| FINAL COMMENT by Arndt Kirk | no assembly problems No wirebond problems. |
PLAQUETTE made READY for ENCAPSULATION on 3/9/2007 by Arndt Kirk
PLAQUETTE encapsulated on 3/9/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 3/9/2007 by Ozhan Koybasi
P_1x2R_142_Aon 3/12/2007 12:33 PM
P_1x2R_142_Aon 3/12/2007 12:33 PM
PLAQUETTE TESTED on 2007-03-12 by Gino Bolla
|
|
|||
|
|
| ROC | ROC0 | ROC1 | |
| Ibias_DAC | 130 | 140 | |
| Vana | 127 | 130 | |
| Cal_Del | 101 | 82 | |
| Vthrs_Comp | 63 | 67 | |
| Unbumped | 0 | 0 | |
| Dead | 0 | 0 | |
| Noisy | 0 | 0 | |
| Undecoded | 0 | 0 | |
| Total BAD | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x2R_142_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x2R_142_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x2R_142_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x2R_142_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x2R_142_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x2R_142_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 115 | 120 |
| Vsf | 140 | 135 |
| VoffsetOp | 55 | 65 |
| VIbias_PH | 100 | 105 |
Noise MAP
![[IMAGE] of](P_1x2R_142_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x2R_142_A-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
