| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x2R_115_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 48 V |
| Operational Voltage 88 V |
Parts committed by Arndt Kirk on date 3/1/2007
| Part | ID |
|---|---|
| BBM | BBM_115-1x2T |
| VHDI | 1x2R_277 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W34_XA4K3PT | 54C |
| ROC1 | W34_XA4K3PT | 54B |
Inspected by Arndt Kirk on date 3/7/2007
| LR_dev | 0.022 |
| LL_dev | 0.021 |
| FINAL COMMENT by Arndt Kirk | No assembly problems. No wirebond problem. |
PLAQUETTE made READY for ENCAPSULATION on 3/7/2007 by Arndt Kirk
PLAQUETTE encapsulated on 3/7/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 3/7/2007 by Ozhan Koybasi
P_1x2R_115_Aon 3/8/2007 10:26 AM
P_1x2R_115_Aon 3/8/2007 10:26 AM
PLAQUETTE TESTED on 2007-03-08 by Joseph Clampitt
|
|
|||
|
|
| ROC | ROC0 | ROC1 | |
| Ibias_DAC | 140 | 144 | |
| Vana | 131 | 126 | |
| Cal_Del | 87 | 83 | |
| Vthrs_Comp | 78 | 76 | |
| Unbumped | 0 | 0 | |
| Dead | 0 | 0 | |
| Noisy | 0 | 0 | |
| Undecoded | 0 | 0 | |
| Total BAD | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x2R_115_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x2R_115_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x2R_115_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x2R_115_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x2R_115_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x2R_115_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 155 | 105 |
| Vsf | 140 | 140 |
| VoffsetOp | 80 | 80 |
| VIbias_PH | 100 | 100 |
Noise MAP
![[IMAGE] of](P_1x2R_115_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x2R_115_A-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
