P_1x2L_107_A

Parts committed by Bolla Gino on date 12/18/2006

PartID
BBMBBM_107-1x2T
VHDI1x2L_221

ROCROC waferLabel
ROC0W13_XX4JPAT33C
ROC1W13_XX4JPAT33B

Inspected by Lockwood Gale on date 12/20/2006
LR_dev0.125
LL_dev0.123
FINAL COMMENT by Lockwood GaleNo assembly problems. No problems wirebonding.

PLAQUETTE made READY for testing on 12/20/2006 by Lockwood Gale

P_1x2L_107_Aon 1/3/2007 9:08 AM

PLAQUETTE TESTED on 2007-01-03 by Gino Bolla

[IMAGE] of
IV_XML-File
Maximum Voltage 600 V
[IMAGE] of
LASER_XML-File
Depletion Voltage 50 V
Operational Voltage 90 V

ROCROC0ROC1
Ibias_DAC128126
Vana126125
Cal_Del6492
Vthrs_Comp9060
Unbumped00
Dead00
Noisy00
Undecoded00
Total BAD00

ASSEMBLY_XML-File SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
[IMAGE] of I_BIAS_DAC_XML-File
[IMAGE] of VANA_XML-File
[IMAGE] of DEAD_XML-File
[IMAGE] of NOISY_XML-File
[IMAGE] of UNDECODED_XML-File
[IMAGE] of LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

PLAQUETTE encapsulated on 2007-01-11 by Arndt Kirk

P_1x2L_107_A-1on 1/15/2007 1:36 PM AFTER POTTING

Shipped on date 2007-01-15

Plaquette assigned to panel P4L_028
