![[IMAGE] of](P_1x2L_047_C_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_1x2L_047_C_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 46 V |
| Operational Voltage 86 V |
Parts committed by Bolla Gino on date 2/16/2007
| Part | ID |
|---|---|
| BBM | BBM_047-1x2T |
| VHDI | 1x2L_245 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XG4KFCT | 51D |
| ROC1 | XG4KFCT | 49A |
Inspected by Arndt Kirk on date 2/23/2007
| LR_dev | 0.154 |
| LL_dev | 0.136 |
| FINAL COMMENT by Arndt Kirk | No assembly problems. No wirebond problem. |
PLAQUETTE made READY for ENCAPSULATION on 2/23/2007 by Arndt Kirk
PLAQUETTE encapsulated on 2/26/2007 by Arndt Kirk
PLAQUETTE made READY for testing on 2/26/2007 by Arndt Kirk
P_1x2L_047_Con 3/2/2007 9:57 AM
P_1x2L_047_Con 3/2/2007 9:57 AM
PLAQUETTE TESTED on 2007-03-02 by Cameron McKinney
|
|
|||
|
|
| ROC | ROC0 | ROC1 | |
| Ibias_DAC | 128 | 130 | |
| Vana | 142 | 123 | |
| Cal_Del | 95 | 86 | |
| Vthrs_Comp | 82 | 85 | |
| Unbumped | 0 | 0 | |
| Dead | 0 | 0 | |
| Noisy | 0 | 0 | |
| Undecoded | 0 | 0 | |
| Total BAD | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_1x2L_047_C_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_1x2L_047_C_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_1x2L_047_CDead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_1x2L_047_CNoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_1x2L_047_CUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_1x2L_047_Cno-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 100 | 120 |
| Vsf | 140 | 130 |
| VoffsetOp | 85 | 90 |
| VIbias_PH | 100 | 105 |
Noise MAP
![[IMAGE] of](P_1x2L_047_C-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x2L_047_C-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
