Sensor: S_1x2L_04, Data for leakage current measurement , and plot on overall it is a GOOD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | XG4KFCT | 51D |
| ROC1 | XG4KFCT | 49A |
| Ibias_DAC, Ibias_DAC Data | 128 | 130 |
| Vana, VanaData | 142 | 123 |
| CalDelData and plots | 95 | 86 |
| VthrCompData and plots | 82 | 85 | Depletion Voltage is -46 and suggested operational voltage is -86
| TestDdata ,TestD Plots | 0 | 0 |
| LightData ,Light Plots | 0 | 0 |
| Pass/Fail TestD | GOOD | GOOD |
| Pass/Fail LIGHT | GOOD | GOOD |
Noise MAP
![[IMAGE] of](P_1x2L_047_C-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_1x2L_047_C-580-efficiency.jpg)
EXTRA DACs for NOISE
| VHldDe | 100 | 120 |
| Vsf | 140 | 130 |
| VoffsetOp | 85 | 90 |
| VIbias_PH | 100 | 105 |
| ROC0 NOISE | ![[IMAGE] of](P_1x2L_047_C-580-noise-ROC0-MAP.jpg) | ![[IMAGE] of](P_1x2L_047_C-580-noise-ROC0-HISTO.jpg) | MEAN = 5.379506SIGMA = 0.412477 |
| ROC1 NOISE | ![[IMAGE] of](P_1x2L_047_C-580-noise-ROC1-MAP.jpg) | ![[IMAGE] of](P_1x2L_047_C-580-noise-ROC1-HISTO.jpg) | MEAN = 5.174445SIGMA = 0.425441 |
Comment (if any): Good
This Device have been tested 0Times prior to this one and here are the links to the previous tests:End testing time: 10:15 AM
