Test Date: 2016-06-01 10:26
Analysis date: 2016-06-13 13:14
Analysis date: 2016-06-13 13:14
M-Y-T-NK XRayHRQualification
Summary
| Module | Module | M-Y-T-NK | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 0/0/16 | |
| PixelDefects | Total Pixel Defects | 52 | |
| BumpBondingDefects | Bump Bonding Defects | 52 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 16 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.94/99.83/99.71 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
0 | 99.96 | 99.88 | 99.64 | 0.13 | 79.3 | 0 | 18.2 | 0/198 | 0 |
|
Chip 1
|
C
|
10 | 99.96 | 99.91 | 99.73 | 0.11 | 54.6 | 10 | 12.6 | 0/194 | 0 |
|
Chip 2
|
C
|
3 | 99.90 | 99.87 | 99.77 | 0.83 | 87.6 | 3 | 20.1 | 0/207 | 0 |
|
Chip 3
|
C
|
0 | 99.95 | 99.87 | 99.62 | 0.12 | 140.8 | 0 | 32.5 | 0/291 | 0 |
|
Chip 4
|
C
|
1 | 99.91 | 99.87 | 99.76 | 0.08 | 151.4 | 1 | 35.0 | 0/295 | 0 |
|
Chip 5
|
C
|
0 | 99.94 | 99.90 | 99.77 | 0.10 | 150.2 | 0 | 34.7 | 0/300 | 0 |
|
Chip 6
|
C
|
0 | 99.93 | 99.89 | 99.78 | 0.14 | 149.8 | 0 | 34.5 | 0/299 | 0 |
|
Chip 7
|
C
|
0 | 99.97 | 99.91 | 99.69 | 0.06 | 100.1 | 0 | 23.0 | 0/216 | 0 |
|
Chip 8
|
C
|
1 | 99.95 | 99.91 | 99.77 | 0.16 | 98.9 | 1 | 22.7 | 0/220 | 0 |
|
Chip 9
|
C
|
0 | 99.95 | 99.88 | 99.63 | 0.11 | 142.8 | 0 | 32.9 | 0/293 | 0 |
|
Chip 10
|
C
|
0 | 99.95 | 99.88 | 99.62 | 0.12 | 141.7 | 0 | 32.6 | 0/295 | 0 |
|
Chip 11
|
C
|
0 | 99.92 | 99.88 | 99.75 | 0.16 | 124.4 | 0 | 28.6 | 0/261 | 0+0/1 |
|
Chip 12
|
C
|
0 | 99.95 | 99.88 | 99.65 | 0.18 | 124.0 | 0 | 28.5 | 0/254 | 0 |
|
Chip 13
|
C
|
11 | 99.96 | 99.91 | 99.75 | 0.09 | 72.0 | 11 | 16.5 | 0/195 | 0 |
|
Chip 14
|
C
|
26 | 99.95 | 99.29 | -1.00 | 0.01 | 29.2 | 26 | 6.7 | 0/193 | 0 |
|
Chip 15
|
C
|
0 | 99.96 | 99.52 | -1.00 | 0.02 | 30.0 | 0 | 6.9 | 0/193 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 1436 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
