Test Date: 2016-05-10 13:40
Analysis date: 2016-05-24 11:31
Analysis date: 2016-05-24 11:31
M-Y-P-NW XRayHRQualification
Summary
| Module | Module | M-Y-P-NW | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 35 | |
| BumpBondingDefects | Bump Bonding Defects | 35 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.51/97.87 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
0 | 100.58 | 94.47 | 74.26 | 448.68 | 22.3 | 68.3 | 0 | 0/0 | 2 |
|
Chip 1
|
A
|
15 | 99.97 | 99.90 | 99.70 | 0.08 | 15.1 | 46.7 | 15 | 0/0 | 0 |
|
Chip 2
|
A
|
2 | 99.96 | 99.92 | 99.77 | 0.12 | 23.3 | 71.8 | 2 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.72 | 0.13 | 36.7 | 113.0 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.13 | 38.3 | 117.8 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.21 | 38.8 | 119.4 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.87 | 99.64 | 0.12 | 38.0 | 116.8 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.87 | 99.62 | 0.16 | 28.1 | 86.6 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.21 | 25.5 | 78.7 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.09 | 32.7 | 100.6 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.91 | 99.76 | 0.08 | 33.1 | 102.0 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.87 | 99.60 | 0.10 | 28.8 | 88.9 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.91 | 99.75 | 0.10 | 29.8 | 91.8 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
3 | 99.97 | 99.91 | 99.72 | 0.08 | 17.1 | 52.8 | 3 | 0/0 | 0 |
|
Chip 14
|
A
|
15 | 99.96 | 99.47 | -1.00 | 0.01 | 7.2 | 22.2 | 15 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.59 | -1.00 | 0.03 | 7.9 | 24.5 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
