Test Date: 2016-07-18 13:27
Analysis date: 2016-07-21 12:07
Analysis date: 2016-07-21 12:07
M-Y-M-NT XRayHRQualification
Summary
| Module | Module | M-Y-M-NT | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 78 | |
| BumpBondingDefects | Bump Bonding Defects | 78 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 1 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.83/99.69 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.88 | 99.65 | 0.15 | 79.6 | 0 | 25.8 | 0/0 | 0 |
|
Chip 1
|
A
|
20 | 99.96 | 99.88 | 99.64 | 0.12 | 55.2 | 20 | 17.8 | 0/0 | 0 |
|
Chip 2
|
A
|
2 | 99.97 | 99.91 | 99.69 | 0.09 | 93.3 | 2 | 30.2 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.90 | 99.78 | 0.12 | 144.6 | 0 | 46.9 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.14 | 149.1 | 0 | 48.4 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.91 | 99.73 | 0.14 | 146.8 | 0 | 47.7 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.87 | 99.59 | 0.20 | 147.0 | 0 | 47.7 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.96 | 99.90 | 99.70 | 0.10 | 114.3 | 1 | 37.0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.97 | 99.89 | 99.63 | 0.07 | 110.5 | 0 | 35.7 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.91 | 99.76 | 0.13 | 124.5 | 0 | 40.5 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.87 | 99.65 | 0.17 | 125.4 | 0 | 40.7 | 0/0 | 0 |
|
Chip 11
|
C
|
1 | 99.94 | 99.90 | 99.76 | 0.14 | 115.7 | 1 | 37.6 | 2/3 | 0+57/3 |
|
Chip 12
|
A
|
0 | 99.94 | 99.87 | 99.62 | 0.43 | 113.8 | 0 | 37.0 | 0/0 | 0 |
|
Chip 13
|
A
|
13 | 99.95 | 99.89 | 99.70 | 0.10 | 72.8 | 13 | 23.6 | 0/0 | 0 |
|
Chip 14
|
A
|
41 | 99.96 | 99.50 | -1.00 | 0.01 | 27.8 | 41 | 8.9 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.32 | -1.00 | 0.04 | 31.9 | 0 | 10.3 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 1814 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
