Test Date: 2016-06-08 12:55
Analysis date: 2016-06-15 17:42
Analysis date: 2016-06-15 17:42
M-Y-K-NN XRayHRQualification
Summary
| Module | Module | M-Y-K-NN | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 53 | |
| BumpBondingDefects | Bump Bonding Defects | 53 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.83/99.68 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 99.96 | 99.87 | 99.59 | 0.13 | 25.5 | 77.5 | 2 | 0/0 | 0 |
|
Chip 1
|
A
|
16 | 99.95 | 99.90 | 99.71 | 0.08 | 17.8 | 54.3 | 16 | 0/0 | 0 |
|
Chip 2
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.05 | 27.2 | 82.7 | 0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.93 | 99.88 | 99.71 | 0.18 | 42.8 | 129.7 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.88 | 99.71 | 0.06 | 44.3 | 134.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.98 | 99.89 | 99.58 | 0.10 | 46.4 | 140.3 | 1 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.94 | 99.91 | 99.81 | 0.08 | 46.0 | 139.1 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.97 | 99.90 | 99.70 | 0.07 | 32.6 | 99.2 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.94 | 99.87 | 99.64 | 0.16 | 27.6 | 84.0 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.86 | 99.56 | 0.11 | 37.2 | 112.9 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.90 | 99.75 | 0.11 | 36.0 | 109.4 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.90 | 99.73 | 0.08 | 32.1 | 97.5 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.90 | 99.72 | 0.16 | 34.1 | 103.5 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
4 | 99.96 | 99.88 | 99.64 | 0.07 | 19.8 | 60.4 | 4 | 0/0 | 0 |
|
Chip 14
|
A
|
30 | 99.94 | 99.12 | -1.00 | 0.03 | 8.4 | 25.8 | 30 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.71 | -1.00 | 0.03 | 9.2 | 28.1 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 135 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
