Test Date: 2016-10-19 14:02
Analysis date: 2017-01-03 18:28
Analysis date: 2017-01-03 18:28
M-Y-F-NZ XRayHRQualification
Summary
| Module | Module | M-Y-F-NZ | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 212 | |
| BumpBondingDefects | Bump Bonding Defects | 212 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.94/99.84/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.13 | 78.8 | 0 | 24.1 | 0/0 | 0 |
|
Chip 1
|
A
|
17 | 99.96 | 99.87 | 99.58 | 0.08 | 55.6 | 17 | 17.0 | 0/0 | 0 |
|
Chip 2
|
A
|
3 | 99.96 | 99.89 | 99.67 | 0.08 | 84.8 | 3 | 25.9 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.90 | 99.76 | 0.14 | 136.2 | 0 | 41.8 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.88 | 99.69 | 0.14 | 143.2 | 0 | 44.0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.94 | 99.88 | 99.68 | 0.14 | 146.5 | 0 | 45.0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.91 | 99.78 | 0.07 | 140.6 | 0 | 43.2 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.89 | 99.68 | 0.15 | 113.5 | 0 | 34.8 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.88 | 99.67 | 0.16 | 99.0 | 0 | 30.3 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.10 | 120.1 | 0 | 36.8 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.88 | 99.62 | 0.16 | 114.8 | 0 | 35.1 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.94 | 99.88 | 99.66 | 0.13 | 107.9 | 0 | 33.0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.80 | 99.67 | 99.26 | 0.39 | 106.5 | 0 | 32.7 | 0/0 | 0 |
|
Chip 13
|
C
|
165 | 99.96 | 99.86 | 99.54 | 0.18 | 63.2 | 165 | 19.3 | 0/0 | 2 |
|
Chip 14
|
A
|
27 | 99.97 | 99.56 | -1.00 | 0.02 | 28.3 | 27 | 8.6 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.75 | -1.00 | 0.02 | 31.5 | 0 | 9.6 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
