Test Date: 2016-04-28 14:11
Analysis date: 2016-05-24 14:18
Analysis date: 2016-05-24 14:18
M-Y-E-NF XRayHRQualification
Summary
| Module | Module | M-Y-E-NF | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 73 | |
| BumpBondingDefects | Bump Bonding Defects | 73 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.85/99.69 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.89 | 99.72 | 0.21 | 72.5 | 0 | 24.6 | 0/0 | 0 |
|
Chip 1
|
A
|
20 | 99.96 | 99.89 | 99.68 | 0.10 | 49.1 | 20 | 16.6 | 0/0 | 0 |
|
Chip 2
|
A
|
9 | 99.95 | 99.88 | 99.68 | 0.07 | 76.1 | 9 | 25.7 | 0/0 | 0 |
|
Chip 3
|
A
|
3 | 99.96 | 99.89 | 99.65 | 0.18 | 123.2 | 3 | 41.9 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.91 | 99.87 | 99.76 | 0.14 | 132.1 | 1 | 44.9 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.26 | 131.7 | 0 | 44.8 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.91 | 99.73 | 0.18 | 133.0 | 0 | 45.2 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.08 | 92.5 | 0 | 31.2 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.95 | 99.89 | 99.70 | 0.11 | 84.0 | 1 | 28.4 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.90 | 99.77 | 0.10 | 109.8 | 0 | 37.2 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.88 | 99.70 | 0.13 | 104.5 | 0 | 35.4 | 0/0 | 0 |
|
Chip 11
|
A
|
3 | 99.93 | 99.87 | 99.67 | 0.21 | 92.1 | 3 | 31.2 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.94 | 99.88 | 99.68 | 0.16 | 96.1 | 0 | 32.5 | 0/0 | 0 |
|
Chip 13
|
A
|
5 | 99.95 | 99.85 | 99.53 | 0.11 | 57.5 | 5 | 19.4 | 0/0 | 0 |
|
Chip 14
|
A
|
31 | 99.96 | 99.43 | -1.00 | 0.02 | 25.0 | 31 | 8.4 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.78 | -1.00 | 0.02 | 26.1 | 0 | 8.8 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 18 | |
| nWarnings | # Warnings | 1041 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 2 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
