Test Date: 2016-05-17 10:29
Analysis date: 2016-05-24 22:47
Analysis date: 2016-05-24 22:47
M-Y-A-NS XRayHRQualification
Summary
| Module | Module | M-Y-A-NS | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 39 | |
| BumpBondingDefects | Bump Bonding Defects | 39 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.84/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.88 | 99.63 | 0.14 | 24.2 | 75.4 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
7 | 99.96 | 99.87 | 99.59 | 0.11 | 16.0 | 50.1 | 7 | 0/0 | 0 |
|
Chip 2
|
A
|
3 | 99.96 | 99.89 | 99.65 | 0.07 | 24.7 | 77.1 | 3 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.85 | 99.52 | 0.21 | 41.4 | 129.0 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.95 | 99.88 | 99.66 | 0.19 | 45.5 | 141.5 | 1 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.93 | 99.90 | 99.81 | 0.12 | 43.1 | 133.8 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.88 | 99.59 | 0.10 | 43.6 | 135.5 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.13 | 33.8 | 105.3 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.68 | 0.14 | 31.1 | 97.0 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.93 | 99.87 | 99.69 | 0.12 | 39.8 | 124.0 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.90 | 99.78 | 0.13 | 39.0 | 121.3 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.94 | 99.88 | 99.68 | 0.13 | 34.5 | 107.5 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.95 | 99.90 | 99.73 | 0.14 | 36.0 | 112.3 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
3 | 99.95 | 99.89 | 99.69 | 0.12 | 20.4 | 63.5 | 3 | 0/0 | 0 |
|
Chip 14
|
A
|
20 | 99.96 | 99.47 | -1.00 | 0.02 | 8.3 | 25.9 | 20 | 0/0 | 0 |
|
Chip 15
|
A
|
4 | 99.96 | 99.56 | -1.00 | 0.03 | 9.6 | 29.9 | 4 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 27 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
