Test Date: 2016-09-01 13:25
Analysis date: 2016-09-02 11:15
Analysis date: 2016-09-02 11:15
M-Q-A-44 XRayHRQualification
Summary
| Module | Module | M-Q-A-44 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 90 | |
| BumpBondingDefects | Bump Bonding Defects | 90 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.81/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.89 | 99.68 | 0.11 | 74.7 | 0 | 22.5 | 0/0 | 0 |
|
Chip 1
|
A
|
29 | 99.96 | 99.88 | 99.62 | 0.09 | 47.8 | 29 | 14.3 | 0/0 | 0 |
|
Chip 2
|
A
|
4 | 99.97 | 99.88 | 99.58 | 0.08 | 69.2 | 4 | 20.8 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.87 | 99.56 | 0.13 | 107.2 | 0 | 32.2 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.87 | 99.62 | 0.20 | 112.9 | 0 | 33.9 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.94 | 99.88 | 99.66 | 0.10 | 114.2 | 0 | 34.3 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.93 | 99.89 | 99.76 | 0.25 | 115.1 | 0 | 34.6 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.16 | 77.0 | 0 | 23.1 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.86 | 99.52 | 0.12 | 71.7 | 0 | 21.4 | 0/0 | 0 |
|
Chip 9
|
A
|
2 | 99.95 | 99.87 | 99.60 | 0.16 | 100.3 | 2 | 30.1 | 0/0 | 0 |
|
Chip 10
|
A
|
1 | 99.96 | 99.89 | 99.67 | 0.13 | 100.9 | 1 | 30.3 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.89 | 99.67 | 0.11 | 83.3 | 0 | 25.0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.22 | 89.9 | 0 | 27.0 | 0/0 | 0 |
|
Chip 13
|
A
|
3 | 99.96 | 99.88 | 99.62 | 0.11 | 55.1 | 3 | 16.5 | 0/0 | 0 |
|
Chip 14
|
A
|
50 | 99.94 | 99.22 | -1.00 | 0.02 | 21.8 | 50 | 6.5 | 0/0 | 0 |
|
Chip 15
|
A
|
1 | 99.95 | 99.34 | -1.00 | 0.04 | 23.4 | 1 | 7.0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 63 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
