Test Date: 2016-09-27 13:37
Analysis date: 2016-10-05 16:28
Analysis date: 2016-10-05 16:28
M-Q-A-19 XRayHRQualification
Summary
| Module | Module | M-Q-A-19 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 106 | |
| BumpBondingDefects | Bump Bonding Defects | 106 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.79/99.66/99.49 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.08 | 17.2 | 55.2 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
15 | 99.97 | 99.89 | 99.63 | 0.06 | 11.5 | 36.9 | 15 | 0/0 | 0 |
|
Chip 2
|
A
|
5 | 99.97 | 99.88 | 99.60 | 0.10 | 19.3 | 62.0 | 5 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.09 | 29.1 | 93.0 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.95 | 99.88 | 99.63 | 0.13 | 30.3 | 97.1 | 1 | 0/0 | 0 |
|
Chip 5
|
C
|
33 | 97.28 | 97.28 | 97.28 | 25316.45 | 30.9 | 98.7 | 33 | 0/0 | 2+0/1 |
|
Chip 6
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.12 | 31.6 | 101.2 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.14 | 22.1 | 70.8 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.12 | 19.2 | 61.8 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.95 | 99.89 | 99.69 | 0.14 | 25.8 | 82.4 | 1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.89 | 99.66 | 0.13 | 25.3 | 81.0 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.11 | 21.1 | 67.8 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.96 | 99.89 | 99.67 | 0.12 | 22.4 | 71.9 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
10 | 99.95 | 99.88 | 99.68 | 0.14 | 13.3 | 42.8 | 10 | 0/0 | 0 |
|
Chip 14
|
A
|
40 | 99.93 | 98.98 | -1.00 | 0.02 | 5.2 | 16.8 | 40 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.76 | -1.00 | 0.01 | 6.6 | 21.2 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
