Test Date: 2016-09-12 13:16
Analysis date: 2016-09-13 14:53
Analysis date: 2016-09-13 14:53
M-Q-A-07 XRayHRQualification
Summary
| Module | Module | M-Q-A-07 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 9/7/0 | |
| PixelDefects | Total Pixel Defects | 97 | |
| BumpBondingDefects | Bump Bonding Defects | 97 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.80/99.38/97.90 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
1 | 99.39 | 99.01 | 97.76 | 92.15 | 18.7 | 60.4 | 1 | 0/0 | 0 |
|
Chip 1
|
A
|
28 | 99.18 | 99.15 | 99.03 | 97.45 | 11.9 | 38.5 | 28 | 0/0 | 0 |
|
Chip 2
|
B
|
6 | 99.30 | 98.75 | 96.93 | 91.60 | 18.1 | 58.4 | 6 | 0/0 | 0 |
|
Chip 3
|
B
|
0 | 99.96 | 99.01 | 95.87 | 39.26 | 28.8 | 92.8 | 0 | 0/0 | 0 |
|
Chip 4
|
B
|
0 | 100.10 | 99.07 | 95.64 | 7.31 | 30.4 | 97.9 | 0 | 0/0 | 0 |
|
Chip 5
|
B
|
0 | 100.05 | 99.08 | 95.86 | 21.22 | 30.4 | 97.9 | 0 | 0/0 | 0 |
|
Chip 6
|
B
|
0 | 100.05 | 99.01 | 95.60 | 23.03 | 30.4 | 97.7 | 0 | 0/0 | 0 |
|
Chip 7
|
B
|
0 | 99.62 | 98.79 | 96.07 | 61.02 | 21.9 | 70.6 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.89 | 99.65 | 0.19 | 21.2 | 68.6 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.96 | 99.89 | 99.66 | 0.09 | 29.6 | 95.4 | 1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.90 | 99.72 | 0.13 | 29.6 | 95.3 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.86 | 99.56 | 0.12 | 23.3 | 75.2 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.97 | 99.89 | 99.66 | 0.08 | 24.4 | 78.7 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.96 | 99.87 | 99.57 | 0.14 | 15.2 | 49.1 | 8 | 0/0 | 0 |
|
Chip 14
|
A
|
53 | 99.95 | 99.36 | -1.00 | 0.01 | 5.7 | 18.4 | 53 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.50 | -1.00 | 0.02 | 6.3 | 20.4 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 154 | |
| nWarnings | # Warnings | 20 | |
| channel_0_count | Channel 0 | 19 | |
| channel_1_count | Channel 1 | 7 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 10 | |
| message_eventid_count | Event ID mismatch | 5 | |
| message_readback_count | Readback start marker | 8 | |
| message_notokenpass_count | has NoTokenPass | 3 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
