Test Date: 2016-09-29 10:39
Analysis date: 2016-10-14 14:18
Analysis date: 2016-10-14 14:18
M-Q-A-05 XRayHRQualification
Summary
| Module | Module | M-Q-A-05 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/0/2 | |
| PixelDefects | Total Pixel Defects | 94 | |
| BumpBondingDefects | Bump Bonding Defects | 94 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.51/97.92/91.95 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 99.96 | 99.86 | 99.53 | 0.11 | 16.7 | 51.5 | 1 | 0/0 | 0 |
|
Chip 1
|
A
|
27 | 99.96 | 99.90 | 99.69 | 0.12 | 10.4 | 32.0 | 27 | 0/0 | 0 |
|
Chip 2
|
A
|
6 | 99.96 | 99.89 | 99.65 | 0.07 | 17.0 | 52.4 | 6 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.28 | 27.1 | 83.4 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.86 | 99.55 | 0.25 | 28.5 | 87.7 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.20 | 30.4 | 93.7 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.97 | 99.91 | 99.70 | 0.11 | 30.0 | 92.6 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.97 | 99.87 | 99.57 | 0.08 | 20.9 | 64.6 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.11 | 19.5 | 60.3 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.87 | 99.59 | 0.23 | 24.9 | 76.5 | 0 | 0/0 | 0 |
|
Chip 10
|
C
|
0 | 99.40 | 75.98 | -1.47 | 722.88 | 23.6 | 72.9 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.09 | 21.4 | 66.2 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.96 | 99.88 | 99.62 | 0.11 | 21.6 | 66.6 | 1 | 0/0 | 0 |
|
Chip 13
|
C
|
2 | 93.35 | 93.35 | 93.35 | 60256.48 | 12.6 | 38.5 | 2 | 0/0 | 2 |
|
Chip 14
|
A
|
57 | 99.96 | 99.41 | -1.00 | 0.02 | 5.4 | 16.8 | 57 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.48 | -1.00 | 0.02 | 6.8 | 21.0 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
