Test Date: 2016-08-17 13:11
Analysis date: 2016-08-19 12:42
Analysis date: 2016-08-19 12:42
M-Q-9-30 XRayHRQualification
Summary
| Module | Module | M-Q-9-30 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 88 | |
| BumpBondingDefects | Bump Bonding Defects | 88 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.84/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.11 | 17.9 | 61.9 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
21 | 99.97 | 99.87 | 99.55 | 0.06 | 11.1 | 38.3 | 21 | 0/0 | 0 |
|
Chip 2
|
A
|
8 | 99.96 | 99.92 | 99.76 | 0.10 | 18.0 | 62.4 | 8 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.09 | 28.2 | 97.3 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.91 | 99.77 | 0.08 | 30.7 | 106.0 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.94 | 99.88 | 99.68 | 0.18 | 30.7 | 105.5 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.10 | 30.6 | 105.3 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.88 | 99.64 | 0.11 | 21.1 | 73.1 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.89 | 99.67 | 0.09 | 18.1 | 63.0 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.96 | 99.89 | 99.66 | 0.10 | 25.4 | 87.7 | 1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.87 | 99.61 | 0.15 | 25.2 | 87.2 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.11 | 22.3 | 77.2 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.15 | 23.6 | 81.5 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.96 | 99.88 | 99.61 | 0.10 | 13.6 | 46.9 | 9 | 0/0 | 0 |
|
Chip 14
|
A
|
49 | 99.95 | 99.30 | -1.00 | 0.02 | 5.6 | 19.6 | 49 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.65 | -1.00 | 0.03 | 7.1 | 24.8 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 115 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
