Test Date: 2016-08-19 13:14
Analysis date: 2016-08-25 15:48
Analysis date: 2016-08-25 15:48
M-Q-9-18 XRayHRQualification
Summary
| Module | Module | M-Q-9-18 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/0/2 | |
| PixelDefects | Total Pixel Defects | 238 | |
| BumpBondingDefects | Bump Bonding Defects | 238 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 20/50/80 | 98.67/98.54/98.21 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.08 | 40.8 | 0 | 12.7 | 0/0 | 0 |
|
Chip 1
|
A
|
27 | 99.96 | 99.87 | 99.57 | 0.05 | 37.4 | 27 | 11.7 | 0/0 | 0 |
|
Chip 2
|
A
|
11 | 99.97 | 99.86 | 99.50 | 0.10 | 60.8 | 11 | 19.0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.17 | 96.7 | 0 | 30.4 | 0/0 | 0 |
|
Chip 4
|
C
|
0 | 79.52 | 79.52 | 79.52 | 1376.09 | 107.3 | 0 | 33.5 | 0/0 | 0+0/1 |
|
Chip 5
|
A
|
0 | 99.95 | 99.87 | 99.63 | 0.14 | 104.8 | 0 | 32.9 | 0/0 | 0 |
|
Chip 6
|
A
|
4 | 99.95 | 99.90 | 99.74 | 0.07 | 103.1 | 4 | 32.4 | 0/0 | 0 |
|
Chip 7
|
C
|
160 | 99.85 | 99.80 | 99.67 | 10.64 | 65.3 | 160 | 20.4 | 0/0 | 2 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.68 | 0.06 | 67.4 | 0 | 21.0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.89 | 99.68 | 0.16 | 92.5 | 0 | 29.0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.87 | 99.63 | 0.16 | 90.8 | 0 | 28.5 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.90 | 99.72 | 0.14 | 79.7 | 0 | 24.9 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.10 | 84.7 | 0 | 26.5 | 0/0 | 0 |
|
Chip 13
|
A
|
5 | 99.96 | 99.88 | 99.61 | 0.10 | 49.7 | 5 | 15.6 | 0/0 | 0 |
|
Chip 14
|
A
|
31 | 99.95 | 99.41 | -1.00 | 0.02 | 18.9 | 31 | 5.9 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.33 | -1.00 | 0.04 | 21.3 | 0 | 6.7 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 6 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
