Test Date: 2016-08-31 16:32
Analysis date: 2017-03-29 13:58
Analysis date: 2017-03-29 13:58
M-Q-9-17 XRayHRQualification
Summary
| Module | Module | M-Q-9-17 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 93 | |
| BumpBondingDefects | Bump Bonding Defects | 93 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 1 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.82/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.54 | 0.12 | 63.2 | 0 | 19.4 | 0/0 | 0 |
|
Chip 1
|
A
|
26 | 99.96 | 99.90 | 99.71 | 0.09 | 38.2 | 26 | 11.7 | 0/0 | 0 |
|
Chip 2
|
A
|
9 | 99.96 | 99.90 | 99.69 | 0.10 | 60.0 | 9 | 18.4 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.87 | 99.64 | 0.20 | 92.3 | 0 | 28.3 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.90 | 99.71 | 0.10 | 96.7 | 0 | 29.7 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.10 | 100.3 | 0 | 30.8 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.88 | 99.67 | 0.14 | 95.0 | 0 | 29.1 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.12 | 57.9 | 0 | 17.7 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.14 | 56.7 | 0 | 17.3 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.10 | 79.9 | 0 | 24.5 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.87 | 99.59 | 0.13 | 80.2 | 0 | 24.6 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.87 | 99.58 | 0.11 | 68.5 | 0 | 21.0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.97 | 99.90 | 99.69 | 0.06 | 72.9 | 0 | 22.3 | 0/0 | 0 |
|
Chip 13
|
A
|
10 | 99.97 | 99.86 | 99.51 | 0.25 | 43.5 | 10 | 13.3 | 0/0 | 0 |
|
Chip 14
|
C
|
48 | 99.93 | 99.16 | -1.00 | 0.17 | 16.5 | 48 | 5.1 | 4/4 | 0+72/0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.66 | -1.00 | 0.03 | 18.5 | 0 | 5.6 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
