M-Q-9-04 XRayHRQualification
Summary
| Module | Module | M-Q-9-04 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 250 | |
| BumpBondingDefects | Bump Bonding Defects | 250 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.07 | 22.1 | 69.6 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
25 | 99.95 | 99.86 | 99.56 | 0.12 | 13.5 | 42.4 | 25 | 0/0 | 0 |
|
Chip 2
|
A
|
11 | 99.97 | 99.89 | 99.65 | 0.07 | 20.5 | 64.3 | 11 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.11 | 32.6 | 102.3 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.86 | 99.57 | 0.14 | 35.4 | 111.0 | 0 | 0/0 | 0 |
|
Chip 5
|
C
|
160 | 99.94 | 99.89 | 99.74 | 0.14 | 35.3 | 110.7 | 160 | 0/0 | 2 |
|
Chip 6
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.27 | 35.0 | 109.7 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.89 | 99.69 | 0.09 | 23.8 | 74.8 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.95 | 99.87 | 99.60 | 0.12 | 22.4 | 70.8 | 1 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.08 | 30.1 | 94.6 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.88 | 99.67 | 0.17 | 28.8 | 90.4 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.87 | 99.57 | 0.13 | 24.9 | 78.2 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.95 | 99.86 | 99.58 | 0.10 | 26.1 | 82.2 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
13 | 99.96 | 99.88 | 99.63 | 0.19 | 15.6 | 49.1 | 13 | 0/0 | 0 |
|
Chip 14
|
A
|
39 | 99.97 | 99.60 | -1.00 | 0.01 | 6.2 | 19.6 | 39 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.45 | -1.00 | 0.02 | 6.6 | 20.9 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 172 | |
| nWarnings | # Warnings | 79 | |
| channel_0_count | Channel 0 | 11 | |
| channel_1_count | Channel 1 | 11 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 16 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_readback_count | Readback start marker | 2 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
