M-Q-8-03 XRayHRQualification
Summary
| Module | Module | M-Q-8-03 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 1586 | |
| BumpBondingDefects | Bump Bonding Defects | 1586 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.43/99.00 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.97 | 99.97 | 99.95 | 0.04 | 4.9 | 15.3 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
449 | 99.96 | 99.51 | 98.02 | 0.02 | 3.0 | 9.5 | 449 | 0/0 | 0 |
|
Chip 2
|
A
|
240 | 99.97 | 99.83 | 99.34 | 0.04 | 5.0 | 15.5 | 240 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.97 | 99.87 | 99.52 | 0.02 | 8.1 | 25.4 | 1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.97 | 99.76 | 99.08 | 0.05 | 8.7 | 27.0 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.97 | 99.77 | 99.11 | 0.05 | 8.8 | 27.4 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.97 | 99.77 | 99.12 | 0.06 | 9.1 | 28.3 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
6 | 99.97 | 99.76 | 99.05 | 0.05 | 6.5 | 20.3 | 6 | 0/0 | 0 |
|
Chip 8
|
B
|
1 | 99.95 | 99.36 | 97.39 | 0.04 | 5.9 | 18.5 | 1 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.97 | 99.74 | 98.97 | 0.05 | 7.7 | 24.2 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.97 | 99.78 | 99.18 | 0.05 | 7.5 | 23.6 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
7 | 99.97 | 99.70 | 98.79 | 0.02 | 6.3 | 19.6 | 7 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.97 | 99.77 | 99.10 | 0.03 | 6.2 | 19.4 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
295 | 99.97 | 99.82 | 99.32 | 0.04 | 3.7 | 11.5 | 295 | 0/0 | 0 |
|
Chip 14
|
A
|
587 | 99.89 | 98.28 | -1.00 | 0.00 | 1.4 | 4.3 | 587 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.75 | 96.22 | -1.00 | 0.01 | 1.7 | 5.3 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
