Test Date: 2016-08-19 13:12
Analysis date: 2016-08-24 17:42
Analysis date: 2016-08-24 17:42
M-Q-7-06 XRayHRQualification
Summary
| Module | Module | M-Q-7-06 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 105 | |
| BumpBondingDefects | Bump Bonding Defects | 105 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.78/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.52 | 0.10 | 55.0 | 0 | 15.1 | 0/0 | 0 |
|
Chip 1
|
A
|
34 | 99.96 | 99.89 | 99.65 | 0.09 | 34.7 | 34 | 9.5 | 0/0 | 0 |
|
Chip 2
|
A
|
12 | 99.94 | 99.81 | 99.40 | 0.24 | 56.6 | 12 | 15.5 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.14 | 86.9 | 0 | 23.9 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.97 | 99.89 | 99.65 | 0.08 | 94.4 | 0 | 26.0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.90 | 99.71 | 0.17 | 97.2 | 0 | 26.8 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.18 | 95.7 | 0 | 26.4 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.87 | 99.63 | 0.12 | 67.1 | 0 | 18.4 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.10 | 66.4 | 0 | 18.2 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.89 | 99.69 | 0.15 | 83.5 | 0 | 22.9 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.88 | 99.63 | 0.14 | 81.4 | 0 | 22.4 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.08 | 69.5 | 0 | 19.1 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.88 | 99.63 | 0.10 | 70.8 | 0 | 19.4 | 0/0 | 0 |
|
Chip 13
|
A
|
17 | 99.95 | 99.87 | 99.63 | 0.22 | 43.5 | 17 | 11.9 | 0/0 | 0 |
|
Chip 14
|
A
|
42 | 99.92 | 98.89 | -1.00 | 0.01 | 17.3 | 42 | 4.8 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.29 | -1.00 | 0.03 | 22.1 | 0 | 6.0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 4 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 18 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 4 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
