Test Date: 2016-10-04 13:27
Analysis date: 2016-10-10 13:58
Analysis date: 2016-10-10 13:58
M-Q-7-05 XRayHRQualification
Summary
| Module | Module | M-Q-7-05 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 615 | |
| BumpBondingDefects | Bump Bonding Defects | 615 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.93/99.81/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.93 | 99.87 | 99.64 | 1.98 | 19.1 | 62.1 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
28 | 99.97 | 99.89 | 99.63 | 0.11 | 12.6 | 40.9 | 28 | 0/0 | 0 |
|
Chip 2
|
A
|
12 | 99.97 | 99.90 | 99.67 | 0.07 | 20.1 | 65.4 | 12 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.50 | 99.50 | 99.50 | 624.24 | 29.9 | 97.0 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.88 | 99.68 | 0.15 | 32.4 | 105.2 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.88 | 99.63 | 0.17 | 34.2 | 110.7 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.90 | 99.73 | 0.15 | 33.8 | 109.4 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.87 | 99.58 | 0.13 | 23.9 | 77.7 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.09 | 22.1 | 72.2 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.89 | 99.71 | 0.21 | 28.4 | 92.3 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.12 | 26.9 | 87.4 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.09 | 21.9 | 71.3 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.21 | 22.3 | 72.7 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.96 | 99.88 | 99.60 | 0.11 | 14.8 | 48.3 | 8 | 0/0 | 0 |
|
Chip 14
|
A
|
43 | 99.95 | 99.31 | -1.00 | 0.01 | 6.3 | 20.6 | 43 | 0/0 | 0 |
|
Chip 15
|
A
|
524 | 99.96 | 99.60 | -1.00 | 0.02 | 7.7 | 25.3 | 524 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
