Test Date: 2016-08-29 13:22
Analysis date: 2017-03-31 11:58
Analysis date: 2017-03-31 11:58
M-Q-6-35 XRayHRQualification
Summary
| Module | Module | M-Q-6-35 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 12/0/4 | |
| PixelDefects | Total Pixel Defects | 442 | |
| BumpBondingDefects | Bump Bonding Defects | 442 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 4 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.80/99.60 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.87 | 99.59 | 0.18 | 77.3 | 0 | 23.9 | 0/0 | 0 |
|
Chip 1
|
A
|
30 | 99.96 | 99.89 | 99.62 | 0.12 | 44.5 | 30 | 13.7 | 0/0 | 0 |
|
Chip 2
|
A
|
9 | 99.97 | 99.88 | 99.60 | 0.06 | 65.1 | 9 | 20.1 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.96 | 99.88 | 99.62 | 0.11 | 96.8 | 1 | 29.9 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.11 | 98.9 | 0 | 30.6 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.89 | 99.68 | 0.14 | 99.5 | 0 | 30.8 | 0/0 | 0 |
|
Chip 6
|
C
|
0 | 99.95 | 99.86 | 99.57 | 0.40 | 88.9 | 0 | 29.0 | 0/0 | 1 |
|
Chip 7
|
C
|
1 | 99.96 | 99.89 | 99.65 | 0.12 | 59.2 | 1 | 19.8 | 0/0 | 1 |
|
Chip 8
|
C
|
179 | 99.94 | 99.83 | 99.50 | 0.63 | 67.3 | 179 | 30.4 | 0/0 | 12 |
|
Chip 9
|
C
|
59 | 99.86 | 99.76 | 99.44 | 4.51 | 85.6 | 59 | 31.1 | 0/0 | 1 |
|
Chip 10
|
A
|
52 | 99.94 | 99.87 | 99.63 | 0.21 | 81.4 | 52 | 25.8 | 0/0 | 0 |
|
Chip 11
|
A
|
52 | 99.95 | 99.87 | 99.57 | 0.12 | 69.1 | 52 | 21.4 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.89 | 99.64 | 0.06 | 74.7 | 0 | 23.1 | 0/0 | 0 |
|
Chip 13
|
A
|
12 | 99.96 | 99.88 | 99.62 | 0.08 | 45.3 | 12 | 14.0 | 0/0 | 0 |
|
Chip 14
|
A
|
47 | 99.94 | 99.20 | -1.00 | 0.02 | 19.5 | 47 | 6.0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.40 | -1.00 | 0.02 | 22.7 | 0 | 7.0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
