M-Q-6-29 XRayHRQualification
Summary
| Module | Module | M-Q-6-29 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.88/99.75/99.61 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.82 | 99.38 | 0.21 | 12.3 | 36.6 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.96 | 99.87 | 99.59 | 0.06 | 8.6 | 25.8 | 0 | 0/0 | 0 |
|
Chip 2
|
A
|
1 | 99.95 | 99.88 | 99.65 | 0.14 | 14.8 | 44.1 | 1 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.90 | 99.85 | 99.70 | 0.25 | 21.9 | 65.1 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.18 | 23.1 | 68.6 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.93 | 99.88 | 99.72 | 0.18 | 23.1 | 68.6 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
1 | 99.90 | 99.85 | 99.71 | 0.15 | 22.7 | 67.4 | 1 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.20 | 99.16 | 99.02 | 0.92 | 22.2 | 65.9 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.89 | 99.86 | 99.77 | 0.24 | 24.5 | 72.9 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.92 | 99.86 | 99.64 | 0.30 | 24.2 | 72.0 | 1 | 0/0 | 0 |
|
Chip 10
|
A
|
1 | 99.91 | 99.86 | 99.70 | 0.18 | 24.2 | 72.1 | 1 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.92 | 99.87 | 99.68 | 0.20 | 22.2 | 66.2 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.92 | 99.87 | 99.70 | 0.31 | 23.0 | 68.3 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.95 | 99.87 | 99.58 | 0.14 | 15.3 | 45.5 | 0 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.97 | 99.83 | -1.00 | 0.04 | 9.3 | 27.6 | 0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.92 | 98.75 | -1.00 | 0.15 | 11.7 | 34.9 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
