Test Date: 2016-09-06 16:44
Analysis date: 2016-09-15 20:20
Analysis date: 2016-09-15 20:20
M-Q-6-27 XRayHRQualification
Summary
| Module | Module | M-Q-6-27 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 69 | |
| BumpBondingDefects | Bump Bonding Defects | 69 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.80/99.62 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.52 | 0.08 | 17.3 | 55.1 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
25 | 99.96 | 99.87 | 99.58 | 0.08 | 10.6 | 33.6 | 25 | 0/0 | 0 |
|
Chip 2
|
A
|
5 | 99.96 | 99.91 | 99.74 | 0.08 | 16.8 | 53.7 | 5 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.96 | 99.88 | 99.62 | 0.17 | 26.1 | 83.3 | 1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.09 | 27.2 | 86.5 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.87 | 99.62 | 0.19 | 27.9 | 88.6 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.87 | 99.61 | 0.11 | 26.0 | 82.9 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.89 | 99.67 | 0.13 | 19.4 | 61.7 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.93 | 99.84 | 99.55 | 0.94 | 17.9 | 57.0 | 1 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.87 | 99.59 | 0.13 | 22.4 | 71.3 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.86 | 99.58 | 0.20 | 23.2 | 74.2 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.96 | 99.89 | 99.65 | 0.08 | 20.1 | 64.3 | 1 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.97 | 99.90 | 99.66 | 0.16 | 20.8 | 66.4 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
6 | 99.95 | 99.87 | 99.59 | 0.16 | 12.7 | 40.5 | 6 | 0/0 | 0 |
|
Chip 14
|
A
|
30 | 99.93 | 99.04 | -1.00 | 0.01 | 5.1 | 16.4 | 30 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.44 | -1.00 | 0.03 | 6.2 | 19.7 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
