M-Q-6-27 XRayHRQualification
Summary
| Module | Module | M-Q-6-27 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/0/2 | |
| PixelDefects | Total Pixel Defects | 72 | |
| BumpBondingDefects | Bump Bonding Defects | 72 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.60 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.51 | 0.11 | 57.4 | 0 | 17.5 | 0/0 | 0 |
|
Chip 1
|
A
|
16 | 99.96 | 99.87 | 99.55 | 0.07 | 35.1 | 16 | 10.8 | 0/0 | 0 |
|
Chip 2
|
A
|
4 | 99.96 | 99.88 | 99.62 | 0.10 | 56.1 | 4 | 17.2 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.97 | 99.88 | 99.61 | 0.12 | 87.0 | 1 | 26.7 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.88 | 99.64 | 0.10 | 90.1 | 0 | 27.8 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.20 | 92.3 | 0 | 28.6 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.23 | 85.6 | 0 | 26.7 | 0/0 | 0 |
|
Chip 7
|
C
|
1 | 99.97 | 99.88 | 99.58 | 0.11 | 64.2 | 1 | 20.0 | 0/0 | 1 |
|
Chip 8
|
C
|
9 | 99.93 | 99.84 | 99.55 | 1.27 | 58.4 | 9 | 18.1 | 0/0 | 1 |
|
Chip 9
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.11 | 73.5 | 0 | 23.1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.10 | 77.0 | 0 | 23.8 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.96 | 99.88 | 99.61 | 0.11 | 66.9 | 1 | 20.6 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.87 | 99.57 | 0.11 | 69.2 | 0 | 21.3 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.97 | 99.88 | 99.61 | 0.10 | 42.3 | 8 | 13.0 | 0/0 | 0 |
|
Chip 14
|
A
|
32 | 99.95 | 99.32 | -1.00 | 0.02 | 17.2 | 32 | 5.2 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.65 | -1.00 | 0.03 | 20.8 | 0 | 6.3 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
