M-Q-6-24 XRayHRQualification
Summary
| Module | Module | M-Q-6-24 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 160 | |
| BumpBondingDefects | Bump Bonding Defects | 160 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.92/99.85/99.67 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.85 | 99.51 | 0.11 | 42.5 | 0 | 12.6 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.96 | 99.85 | 99.52 | 0.15 | 26.9 | 0 | 7.9 | 0/0 | 0 |
|
Chip 2
|
A
|
0 | 99.94 | 99.89 | 99.71 | 0.15 | 44.2 | 0 | 13.1 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.93 | 99.88 | 99.72 | 0.14 | 62.1 | 0 | 18.4 | 0/0 | 0 |
|
Chip 4
|
C
|
160 | 99.92 | 99.87 | 99.72 | 0.15 | 61.3 | 160 | 18.2 | 0/0 | 2+0/26 |
|
Chip 5
|
A
|
0 | 99.93 | 99.87 | 99.69 | 0.15 | 65.8 | 0 | 19.5 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.92 | 99.88 | 99.75 | 0.17 | 64.9 | 0 | 19.2 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.94 | 99.88 | 99.69 | 0.19 | 58.3 | 0 | 17.2 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.94 | 99.87 | 99.64 | 0.17 | 56.8 | 0 | 16.9 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.91 | 99.87 | 99.70 | 0.21 | 66.2 | 0 | 19.6 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.88 | 99.68 | 0.13 | 64.9 | 0 | 19.3 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.92 | 99.87 | 99.70 | 0.21 | 62.1 | 0 | 18.4 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.92 | 99.86 | 99.64 | 0.23 | 63.3 | 0 | 18.8 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.95 | 99.88 | 99.67 | 0.11 | 43.1 | 0 | 12.8 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.96 | 99.60 | -1.00 | 0.04 | 23.8 | 0 | 7.0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.75 | 99.75 | -1.00 | 21.97 | 31.3 | 0 | 9.2 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 8 | |
| nErrors | # Errors | 337 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 29 | |
| channel_1_count | Channel 1 | 22 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 27 | |
| message_eventid_count | Event ID mismatch | 11 | |
| message_readback_count | Readback start marker | 2 | |
| message_notokenpass_count | has NoTokenPass | 11 | |
| message_datasize_count | Data size criticals | 4 | |
| message_missingevents_count | Missing Event criticals | 4 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
