Test Date: 2016-09-08 13:58
Analysis date: 2016-09-16 11:48
Analysis date: 2016-09-16 11:48
M-Q-6-23 XRayHRQualification
Summary
| Module | Module | M-Q-6-23 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 104 | |
| BumpBondingDefects | Bump Bonding Defects | 104 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.80/99.62 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.87 | 99.58 | 0.09 | 59.6 | 0 | 18.8 | 0/0 | 0 |
|
Chip 1
|
A
|
25 | 99.97 | 99.89 | 99.63 | 0.09 | 36.7 | 25 | 11.6 | 0/0 | 0 |
|
Chip 2
|
A
|
7 | 99.97 | 99.88 | 99.62 | 0.12 | 58.1 | 7 | 18.3 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.12 | 91.4 | 0 | 28.9 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.22 | 94.3 | 0 | 29.8 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.96 | 99.88 | 99.61 | 0.20 | 96.6 | 1 | 30.5 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.21 | 96.7 | 0 | 30.6 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.96 | 99.87 | 99.57 | 0.18 | 69.4 | 1 | 21.9 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.86 | 99.57 | 0.18 | 66.6 | 0 | 21.0 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.95 | 99.87 | 99.59 | 0.19 | 85.7 | 1 | 27.0 | 0/0 | 0 |
|
Chip 10
|
A
|
1 | 99.95 | 99.89 | 99.69 | 0.27 | 87.6 | 1 | 27.7 | 0/0 | 0 |
|
Chip 11
|
A
|
3 | 99.95 | 99.86 | 99.57 | 0.11 | 73.5 | 3 | 23.2 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.89 | 99.67 | 0.08 | 74.9 | 0 | 23.7 | 0/0 | 0 |
|
Chip 13
|
A
|
15 | 99.95 | 99.89 | 99.70 | 0.18 | 45.5 | 15 | 14.3 | 0/0 | 0 |
|
Chip 14
|
A
|
50 | 99.95 | 99.39 | -1.00 | 0.02 | 17.1 | 50 | 5.4 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.93 | 99.07 | -1.00 | 0.04 | 22.4 | 0 | 7.0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
