Test Date: 2016-08-23 13:57
Analysis date: 2016-08-29 14:38
Analysis date: 2016-08-29 14:38
M-Q-6-07 XRayHRQualification
Summary
| Module | Module | M-Q-6-07 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 97 | |
| BumpBondingDefects | Bump Bonding Defects | 97 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.84/99.65 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.54 | 0.08 | 14.8 | 47.9 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
32 | 99.96 | 99.88 | 99.61 | 0.08 | 11.6 | 37.5 | 32 | 0/0 | 0 |
|
Chip 2
|
A
|
6 | 99.95 | 99.87 | 99.59 | 0.10 | 19.0 | 61.6 | 6 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.95 | 99.90 | 99.71 | 0.09 | 30.9 | 100.2 | 1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.91 | 99.76 | 0.12 | 33.5 | 108.4 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.94 | 99.89 | 99.71 | 0.20 | 33.7 | 109.1 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.90 | 99.75 | 0.13 | 34.3 | 111.0 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.96 | 99.87 | 99.56 | 0.10 | 25.5 | 82.8 | 1 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.88 | 99.62 | 0.13 | 23.1 | 75.2 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.87 | 99.63 | 0.20 | 28.9 | 93.4 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.10 | 27.4 | 88.6 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.87 | 99.58 | 0.11 | 22.8 | 73.6 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.10 | 23.6 | 76.4 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
16 | 99.96 | 99.90 | 99.70 | 0.14 | 13.4 | 43.5 | 16 | 0/0 | 0 |
|
Chip 14
|
A
|
38 | 99.95 | 99.32 | -1.00 | 0.01 | 5.6 | 18.0 | 38 | 0/0 | 0 |
|
Chip 15
|
A
|
3 | 99.97 | 99.78 | -1.00 | 0.02 | 6.5 | 21.1 | 3 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
