M-Q-5-50 XRayHRQualification
Summary
| Module | Module | M-Q-5-50 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1681 | |
| BumpBondingDefects | Bump Bonding Defects | 1681 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.82/99.65 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.97 | 99.88 | 99.60 | 0.08 | 63.0 | 0 | 18.7 | 0/0 | 0 |
|
Chip 1
|
A
|
37 | 99.95 | 99.87 | 99.57 | 0.07 | 35.9 | 37 | 10.7 | 0/0 | 0 |
|
Chip 2
|
A
|
13 | 99.95 | 99.89 | 99.68 | 0.11 | 59.9 | 13 | 17.8 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.21 | 92.7 | 0 | 27.5 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.89 | 99.70 | 0.09 | 99.1 | 0 | 29.5 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.88 | 99.67 | 0.14 | 99.3 | 0 | 29.6 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.14 | 96.4 | 0 | 28.8 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.95 | 99.87 | 99.60 | 0.08 | 69.3 | 1 | 20.6 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.68 | 0.12 | 78.1 | 0 | 23.2 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.06 | 102.1 | 0 | 30.4 | 0/0 | 0 |
|
Chip 10
|
A
|
1564 | 99.96 | 99.90 | 99.70 | 0.12 | 80.2 | 1564 | 23.9 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.94 | 99.87 | 99.62 | 0.11 | 86.7 | 1 | 25.8 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.97 | 99.89 | 99.61 | 0.12 | 91.6 | 0 | 27.2 | 0/0 | 0 |
|
Chip 13
|
A
|
13 | 99.96 | 99.88 | 99.64 | 0.13 | 55.2 | 13 | 16.4 | 0/0 | 0 |
|
Chip 14
|
A
|
52 | 99.95 | 99.37 | -1.00 | 0.02 | 20.7 | 52 | 6.1 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.39 | -1.00 | 0.03 | 24.4 | 0 | 7.2 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
