Test Date: 2016-10-03 13:31
Analysis date: 2016-10-06 23:29
Analysis date: 2016-10-06 23:29
M-Q-5-30 XRayHRQualification
Summary
| Module | Module | M-Q-5-30 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 57 | |
| BumpBondingDefects | Bump Bonding Defects | 57 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.91/99.77/99.57 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.87 | 99.60 | 0.09 | 16.1 | 52.6 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
21 | 99.96 | 99.87 | 99.57 | 0.08 | 10.1 | 33.1 | 21 | 0/0 | 0 |
|
Chip 2
|
A
|
4 | 99.96 | 99.87 | 99.57 | 0.13 | 16.5 | 53.7 | 4 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.96 | 99.90 | 99.69 | 0.07 | 25.5 | 83.1 | 1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.87 | 99.62 | 0.24 | 28.2 | 91.6 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.90 | 99.67 | 0.13 | 27.6 | 89.8 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.12 | 28.3 | 92.0 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.89 | 99.67 | 0.10 | 19.9 | 64.9 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.89 | 99.71 | 0.14 | 17.9 | 58.3 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.08 | 23.8 | 77.5 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.16 | 99.09 | 98.86 | 65.08 | 22.5 | 73.3 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.87 | 99.59 | 0.09 | 19.4 | 63.1 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.09 | 19.3 | 62.9 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
3 | 99.96 | 99.86 | 99.52 | 0.16 | 11.8 | 38.5 | 3 | 0/0 | 0 |
|
Chip 14
|
A
|
28 | 99.95 | 99.28 | -1.00 | 0.02 | 5.2 | 17.0 | 28 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.53 | -1.00 | 0.03 | 6.0 | 19.8 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
