Test Date: 2017-02-01 14:29
Analysis date: 2017-02-24 11:05
Analysis date: 2017-02-24 11:05
M-Q-5-26 XRayHRQualification
Summary
| Module | Module | M-Q-5-26 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 120 | |
| BumpBondingDefects | Bump Bonding Defects | 120 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.54/99.50/99.38 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.10 | 17.0 | 56.5 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
30 | 99.96 | 99.88 | 99.64 | 0.14 | 10.7 | 35.6 | 30 | 0/0 | 0 |
|
Chip 2
|
A
|
5 | 99.97 | 99.91 | 99.72 | 0.07 | 17.3 | 57.4 | 5 | 0/0 | 0 |
|
Chip 3
|
A
|
2 | 99.96 | 99.89 | 99.67 | 0.10 | 26.5 | 87.5 | 2 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.09 | 28.7 | 94.8 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
2 | 99.96 | 99.90 | 99.71 | 0.14 | 29.6 | 97.7 | 2 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.20 | 28.7 | 94.5 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
9 | 99.97 | 99.88 | 99.60 | 0.08 | 20.4 | 67.5 | 9 | 0/0 | 0 |
|
Chip 8
|
A
|
2 | 99.20 | 99.20 | 99.20 | 2.22 | 19.4 | 64.5 | 2 | 0/0 | 0 |
|
Chip 9
|
C
|
1 | 98.62 | 98.54 | 98.29 | 17.52 | 59.8 | 120.3 | 1 | 0/0 | 34 |
|
Chip 10
|
A
|
0 | 99.14 | 99.14 | 99.14 | 2.08 | 24.5 | 81.0 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.19 | 99.19 | 99.19 | 2.22 | 20.8 | 68.8 | 1 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.16 | 99.16 | 99.16 | 2.16 | 22.1 | 73.0 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
7 | 99.17 | 99.15 | 99.08 | 3.03 | 14.1 | 46.9 | 7 | 0/0 | 0 |
|
Chip 14
|
A
|
60 | 99.27 | 99.27 | -1.00 | 3.76 | 5.4 | 17.8 | 60 | 0/0 | 0 |
|
Chip 15
|
A
|
1 | 99.21 | 99.21 | -1.00 | 2.67 | 7.1 | 23.7 | 1 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 2 | |
| nErrors | # Errors | 12 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 4 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 1 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
