Test Date: 2016-09-23 14:06
Analysis date: 2016-09-27 15:48
Analysis date: 2016-09-27 15:48
M-Q-5-17 XRayHRQualification
Summary
| Module | Module | M-Q-5-17 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 95 | |
| BumpBondingDefects | Bump Bonding Defects | 95 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.83/99.65 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.93 | 99.86 | 99.63 | 0.70 | 64.9 | 0 | 20.8 | 0/0 | 0 |
|
Chip 1
|
A
|
17 | 99.96 | 99.86 | 99.55 | 0.14 | 41.8 | 17 | 13.4 | 0/0 | 0 |
|
Chip 2
|
A
|
4 | 99.96 | 99.86 | 99.54 | 0.15 | 67.8 | 4 | 21.7 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.16 | 101.2 | 0 | 32.4 | 0/0 | 0 |
|
Chip 4
|
A
|
2 | 99.94 | 99.87 | 99.66 | 0.19 | 107.7 | 2 | 34.5 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.94 | 99.89 | 99.73 | 0.15 | 114.0 | 1 | 36.6 | 0/0 | 0 |
|
Chip 6
|
A
|
1 | 99.94 | 99.88 | 99.69 | 0.29 | 111.7 | 1 | 35.8 | 0/0 | 0 |
|
Chip 7
|
A
|
8 | 99.96 | 99.89 | 99.67 | 0.10 | 77.2 | 8 | 24.7 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.95 | 99.87 | 99.60 | 0.13 | 75.3 | 1 | 24.0 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.96 | 99.90 | 99.68 | 0.12 | 105.8 | 1 | 33.9 | 0/0 | 0 |
|
Chip 10
|
A
|
1 | 99.97 | 99.92 | 99.75 | 0.08 | 106.4 | 1 | 34.1 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.97 | 99.89 | 99.64 | 0.13 | 88.4 | 1 | 28.3 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.90 | 99.71 | 0.14 | 93.3 | 0 | 29.9 | 0/0 | 0 |
|
Chip 13
|
A
|
13 | 99.95 | 99.87 | 99.63 | 0.10 | 58.5 | 13 | 18.7 | 0/0 | 0 |
|
Chip 14
|
A
|
45 | 99.96 | 99.42 | -1.00 | 0.01 | 20.2 | 45 | 6.5 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.57 | -1.00 | 0.03 | 23.0 | 0 | 7.3 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 41 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
