Test Date: 2016-10-24 13:21
Analysis date: 2016-10-25 14:18
Analysis date: 2016-10-25 14:18
M-Q-4-41 XRayHRQualification
Summary
| Module | Module | M-Q-4-41 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 73 | |
| BumpBondingDefects | Bump Bonding Defects | 73 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.82/99.67 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.04 | 57.4 | 0 | 17.3 | 0/0 | 0 |
|
Chip 1
|
A
|
15 | 99.96 | 99.88 | 99.60 | 0.09 | 36.3 | 15 | 10.9 | 0/0 | 0 |
|
Chip 2
|
A
|
10 | 99.97 | 99.89 | 99.61 | 0.07 | 54.4 | 10 | 16.3 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.68 | 0.11 | 82.6 | 0 | 24.8 | 0/0 | 0 |
|
Chip 4
|
A
|
2 | 99.96 | 99.90 | 99.70 | 0.17 | 87.0 | 2 | 26.2 | 0/0 | 0 |
|
Chip 5
|
A
|
2 | 99.96 | 99.91 | 99.75 | 0.10 | 94.7 | 2 | 28.5 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.16 | 92.9 | 0 | 28.0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.89 | 99.68 | 0.11 | 60.4 | 0 | 18.1 | 0/0 | 0 |
|
Chip 8
|
A
|
5 | 99.96 | 99.88 | 99.63 | 0.15 | 61.2 | 5 | 18.4 | 0/0 | 0 |
|
Chip 9
|
A
|
4 | 99.95 | 99.90 | 99.74 | 0.11 | 90.0 | 4 | 27.1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.88 | 99.65 | 0.12 | 85.1 | 0 | 25.6 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.88 | 99.64 | 0.11 | 68.9 | 0 | 20.8 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.95 | 99.90 | 99.74 | 0.11 | 71.9 | 1 | 21.7 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.96 | 99.90 | 99.71 | 0.20 | 44.0 | 8 | 13.2 | 0/0 | 0 |
|
Chip 14
|
A
|
25 | 99.94 | 99.09 | -1.00 | 0.01 | 18.4 | 25 | 5.5 | 0/0 | 0 |
|
Chip 15
|
A
|
1 | 99.96 | 99.54 | -1.00 | 0.02 | 19.2 | 1 | 5.8 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 12 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
