Test Date: 2016-08-29 13:22
Analysis date: 2017-03-29 12:18
Analysis date: 2017-03-29 12:18
M-Q-4-14 XRayHRQualification
Summary
| Module | Module | M-Q-4-14 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 159 | |
| BumpBondingDefects | Bump Bonding Defects | 159 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.92/99.78/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 99.97 | 99.88 | 99.57 | 0.07 | 14.8 | 50.5 | 1 | 0/0 | 0 |
|
Chip 1
|
A
|
25 | 99.97 | 99.89 | 99.65 | 0.08 | 9.6 | 33.0 | 25 | 0/0 | 0 |
|
Chip 2
|
A
|
9 | 99.96 | 99.88 | 99.61 | 0.11 | 14.7 | 50.3 | 9 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.14 | 23.0 | 78.6 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.89 | 99.67 | 0.10 | 24.0 | 82.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.41 | 99.41 | 99.41 | 1270.58 | 24.7 | 84.3 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.91 | 99.75 | 0.12 | 22.8 | 77.8 | 0 | 0/0 | 0 |
|
Chip 7
|
C
|
71 | 99.96 | 99.88 | 99.63 | 0.12 | 14.7 | 50.2 | 71 | 0/0 | 3 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.12 | 16.1 | 55.1 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.24 | 23.0 | 78.8 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.97 | 99.88 | 99.60 | 0.12 | 23.2 | 79.2 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.97 | 99.90 | 99.70 | 0.08 | 20.1 | 68.6 | 1 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.93 | 99.89 | 99.76 | 0.73 | 21.1 | 72.3 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.95 | 99.89 | 99.66 | 0.15 | 12.6 | 43.0 | 9 | 0/0 | 0 |
|
Chip 14
|
A
|
42 | 99.94 | 99.11 | -1.00 | 0.02 | 5.1 | 17.6 | 42 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.42 | -1.00 | 0.03 | 5.5 | 18.9 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
