Test Date: 2017-03-22 12:55
Analysis date: 2017-03-29 15:28
Analysis date: 2017-03-29 15:28
M-Q-4-13 XRayHRQualification
Summary
| Module | Module | M-Q-4-13 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 144 | |
| BumpBondingDefects | Bump Bonding Defects | 144 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.83/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.56 | 0.11 | 64.0 | 0 | 19.1 | 0/0 | 0 |
|
Chip 1
|
A
|
29 | 99.97 | 99.87 | 99.54 | 0.08 | 38.7 | 29 | 11.5 | 0/0 | 0 |
|
Chip 2
|
A
|
10 | 99.96 | 99.88 | 99.61 | 0.10 | 57.5 | 10 | 17.1 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.72 | 0.10 | 90.9 | 0 | 27.1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.90 | 99.72 | 0.07 | 92.3 | 0 | 27.6 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.15 | 93.3 | 0 | 27.9 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.07 | 94.2 | 0 | 28.1 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.10 | 54.6 | 0 | 16.2 | 0/0 | 0 |
|
Chip 8
|
C
|
34 | 99.92 | 99.85 | 99.65 | 1.56 | 51.1 | 34 | 16.5 | 0/0 | 3 |
|
Chip 9
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.14 | 72.9 | 0 | 21.8 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.08 | 71.7 | 0 | 21.4 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.87 | 99.58 | 0.16 | 66.4 | 0 | 19.8 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.87 | 99.56 | 0.12 | 70.6 | 0 | 21.0 | 0/0 | 0 |
|
Chip 13
|
A
|
17 | 99.95 | 99.92 | 99.80 | 0.10 | 43.2 | 17 | 12.9 | 0/0 | 0 |
|
Chip 14
|
A
|
54 | 99.95 | 99.40 | -1.00 | 0.02 | 18.4 | 54 | 5.5 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.49 | -1.00 | 0.02 | 20.7 | 0 | 6.1 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
