Test Date: 2016-11-01 12:34
Analysis date: 2016-12-28 16:54
Analysis date: 2016-12-28 16:54
M-Q-3-42 XRayHRQualification
Summary
| Module | Module | M-Q-3-42 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 13/0/3 | |
| PixelDefects | Total Pixel Defects | 239 | |
| BumpBondingDefects | Bump Bonding Defects | 239 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 3 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.84/99.67 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.53 | 0.15 | 20.4 | 66.7 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
16 | 99.96 | 99.87 | 99.58 | 0.12 | 12.9 | 42.0 | 16 | 0/0 | 0 |
|
Chip 2
|
C
|
13 | 99.96 | 99.90 | 99.70 | 0.13 | 20.7 | 65.6 | 13 | 0/0 | 1 |
|
Chip 3
|
A
|
0 | 99.94 | 99.87 | 99.66 | 0.13 | 31.6 | 102.9 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.18 | 34.0 | 110.9 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.89 | 99.71 | 0.07 | 33.8 | 109.9 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.09 | 34.5 | 112.5 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.87 | 99.64 | 0.16 | 26.0 | 84.8 | 0 | 0/0 | 0 |
|
Chip 8
|
C
|
1 | 99.95 | 99.88 | 99.66 | 0.12 | 29.8 | 90.4 | 1 | 0/0 | 2 |
|
Chip 9
|
A
|
6 | 99.95 | 99.90 | 99.75 | 0.14 | 33.0 | 107.5 | 6 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.91 | 99.74 | 0.10 | 33.2 | 108.1 | 0 | 0/0 | 0 |
|
Chip 11
|
C
|
160 | 99.96 | 99.89 | 99.69 | 0.15 | 28.5 | 92.9 | 160 | 0/0 | 2 |
|
Chip 12
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.11 | 30.0 | 97.9 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.96 | 99.90 | 99.70 | 0.11 | 18.2 | 59.6 | 9 | 0/0 | 0 |
|
Chip 14
|
A
|
34 | 99.96 | 99.47 | -1.00 | 0.03 | 7.2 | 23.6 | 34 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.49 | -1.00 | 0.03 | 9.1 | 29.4 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
