Test Date: 2016-09-07 13:28
Analysis date: 2016-09-09 17:22
Analysis date: 2016-09-09 17:22
M-Q-3-42 XRayHRQualification
Summary
| Module | Module | M-Q-3-42 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 229 | |
| BumpBondingDefects | Bump Bonding Defects | 229 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.82/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.87 | 99.58 | 0.15 | 62.6 | 0 | 20.4 | 0/0 | 0 |
|
Chip 1
|
A
|
23 | 99.95 | 99.88 | 99.65 | 0.10 | 39.8 | 23 | 12.9 | 0/0 | 0 |
|
Chip 2
|
A
|
5 | 99.97 | 99.86 | 99.49 | 0.06 | 59.9 | 5 | 19.5 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.72 | 0.12 | 93.4 | 0 | 30.3 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.89 | 99.68 | 0.11 | 100.0 | 0 | 32.5 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.13 | 101.1 | 0 | 32.9 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.09 | 102.5 | 0 | 33.4 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.91 | 99.73 | 0.06 | 67.5 | 0 | 21.9 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.93 | 99.89 | 99.75 | 0.24 | 71.6 | 1 | 23.2 | 0/0 | 0 |
|
Chip 9
|
A
|
5 | 99.95 | 99.90 | 99.72 | 0.12 | 99.3 | 5 | 32.3 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.90 | 99.75 | 0.09 | 99.7 | 0 | 32.5 | 0/0 | 0 |
|
Chip 11
|
C
|
160 | 99.95 | 99.87 | 99.59 | 0.20 | 84.3 | 160 | 27.4 | 0/0 | 2 |
|
Chip 12
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.11 | 89.5 | 0 | 29.1 | 0/0 | 0 |
|
Chip 13
|
A
|
6 | 99.95 | 99.85 | 99.53 | 0.16 | 55.3 | 6 | 17.9 | 0/0 | 0 |
|
Chip 14
|
A
|
29 | 99.94 | 99.21 | -1.00 | 0.04 | 21.8 | 29 | 7.1 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.57 | -1.00 | 0.01 | 26.3 | 0 | 8.5 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 88 | |
| nWarnings | # Warnings | 15 | |
| channel_0_count | Channel 0 | 5 | |
| channel_1_count | Channel 1 | 4 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 7 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 1 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
