Test Date: 2016-10-05 13:39
Analysis date: 2016-10-07 16:48
Analysis date: 2016-10-07 16:48
M-Q-2-03 XRayHRQualification
Summary
| Module | Module | M-Q-2-03 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 2265 | |
| BumpBondingDefects | Bump Bonding Defects | 2265 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.92/99.82/99.65 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 99.96 | 99.89 | 99.65 | 0.12 | 58.3 | 4 | 18.4 | 0/0 | 0 |
|
Chip 1
|
A
|
20 | 99.96 | 99.88 | 99.59 | 0.09 | 37.9 | 20 | 12.0 | 0/0 | 0 |
|
Chip 2
|
A
|
9 | 99.96 | 99.90 | 99.70 | 0.07 | 61.4 | 9 | 19.4 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.96 | 99.91 | 99.73 | 0.09 | 86.7 | 1 | 27.5 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.95 | 99.90 | 99.73 | 0.17 | 92.3 | 1 | 29.3 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.95 | 99.89 | 99.70 | 0.12 | 99.1 | 1 | 31.4 | 0/0 | 0 |
|
Chip 6
|
C
|
2186 | 99.97 | 99.88 | 99.57 | 0.13 | 47.0 | 2186 | 14.8 | 0/0 | 15 |
|
Chip 7
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.12 | 69.6 | 0 | 22.0 | 0/0 | 0 |
|
Chip 8
|
A
|
2 | 99.36 | 99.36 | 99.36 | 1800.72 | 61.8 | 2 | 19.5 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.89 | 99.70 | 0.15 | 86.7 | 0 | 27.4 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.07 | 84.5 | 0 | 26.7 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.13 | 70.4 | 0 | 22.2 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.19 | 76.7 | 0 | 24.2 | 0/0 | 0 |
|
Chip 13
|
A
|
14 | 99.95 | 99.88 | 99.65 | 0.16 | 43.6 | 14 | 13.7 | 0/0 | 0 |
|
Chip 14
|
A
|
26 | 99.96 | 99.46 | -1.00 | 0.02 | 18.3 | 26 | 5.8 | 0/0 | 0 |
|
Chip 15
|
A
|
1 | 99.97 | 99.75 | -1.00 | 0.03 | 23.9 | 1 | 7.5 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 5 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
