Test Date: 2016-09-13 19:26
Analysis date: 2016-10-21 13:28
Analysis date: 2016-10-21 13:28
M-P-6-29 XRayHRQualification
Summary
| Module | Module | M-P-6-29 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 113 | |
| BumpBondingDefects | Bump Bonding Defects | 113 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.85/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.56 | 0.12 | 18.3 | 55.8 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
22 | 99.96 | 99.87 | 99.57 | 0.09 | 12.5 | 38.4 | 22 | 0/0 | 0 |
|
Chip 2
|
A
|
12 | 99.96 | 99.89 | 99.66 | 0.09 | 21.1 | 64.8 | 12 | 0/0 | 0 |
|
Chip 3
|
A
|
6 | 99.97 | 99.90 | 99.66 | 0.16 | 33.2 | 101.7 | 6 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.13 | 35.8 | 109.7 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.96 | 99.89 | 99.69 | 0.10 | 37.0 | 113.0 | 1 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.89 | 99.72 | 0.10 | 37.0 | 113.1 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.95 | 99.87 | 99.59 | 0.10 | 28.6 | 87.8 | 1 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.09 | 26.1 | 80.2 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.16 | 33.3 | 101.7 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
3 | 99.95 | 99.88 | 99.63 | 0.26 | 30.9 | 94.5 | 3 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.12 | 26.3 | 80.8 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.87 | 99.60 | 0.10 | 27.0 | 82.9 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
13 | 99.95 | 99.87 | 99.59 | 0.13 | 16.6 | 50.9 | 13 | 0/0 | 0 |
|
Chip 14
|
A
|
54 | 99.96 | 99.56 | -1.00 | 0.02 | 6.5 | 19.9 | 54 | 0/0 | 0 |
|
Chip 15
|
A
|
1 | 99.97 | 99.64 | -1.00 | 0.03 | 7.7 | 23.8 | 1 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 31 | |
| nWarnings | # Warnings | 61 | |
| channel_0_count | Channel 0 | 28 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 16 | |
| message_eventid_count | Event ID mismatch | 9 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 3 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
