Test Date: 2017-04-21 11:22
Analysis date: 2017-05-03 16:18
Analysis date: 2017-05-03 16:18
M-P-6-06 XRayHRQualification
Summary
| Module | Module | M-P-6-06 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 11/0/5 | |
| PixelDefects | Total Pixel Defects | 381 | |
| BumpBondingDefects | Bump Bonding Defects | 381 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 5 | |
| Efficiency | Efficiency 20/50/80 | 99.63/99.51/99.33 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.34 | 99.34 | 99.34 | 11.91 | 19.7 | 64.6 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
30 | 99.43 | 99.43 | 99.43 | 10.67 | 12.6 | 41.2 | 30 | 0/0 | 0 |
|
Chip 2
|
A
|
6 | 99.38 | 99.34 | 99.21 | 14.51 | 18.9 | 62.2 | 6 | 0/0 | 0 |
|
Chip 3
|
A
|
6 | 99.11 | 99.11 | 99.11 | 7.76 | 29.4 | 96.2 | 6 | 0/0 | 0 |
|
Chip 4
|
A
|
18 | 99.02 | 99.02 | 99.02 | 10.29 | 31.3 | 102.0 | 18 | 0/0 | 0 |
|
Chip 5
|
C
|
72 | 98.87 | 98.87 | 98.87 | 9.99 | 42.5 | 108.5 | 72 | 0/0 | 9 |
|
Chip 6
|
C
|
104 | 100.00 | 99.94 | 99.74 | 0.00 | 101.9 | 153.7 | 104 | 0/0 | 6 |
|
Chip 7
|
C
|
93 | 99.24 | 99.00 | 98.19 | 17.56 | 54.9 | 95.6 | 93 | 0/0 | 19 |
|
Chip 8
|
A
|
1 | 99.96 | 99.86 | 99.51 | 0.13 | 20.0 | 65.7 | 1 | 0/0 | 0 |
|
Chip 9
|
C
|
0 | 99.95 | 99.89 | 99.70 | 0.15 | 32.3 | 91.8 | 0 | 0/0 | 1 |
|
Chip 10
|
C
|
0 | 99.95 | 99.88 | 99.62 | 0.50 | 28.7 | 87.3 | 0 | 0/0 | 1 |
|
Chip 11
|
A
|
0 | 99.95 | 99.88 | 99.63 | 0.14 | 23.6 | 77.5 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.95 | 99.87 | 99.61 | 0.11 | 25.9 | 85.0 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.95 | 99.88 | 99.62 | 0.12 | 15.0 | 49.2 | 9 | 0/0 | 0 |
|
Chip 14
|
A
|
41 | 99.96 | 99.43 | -1.00 | 0.01 | 6.0 | 19.6 | 41 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.42 | -1.00 | 0.03 | 6.9 | 22.7 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
