Test Date: 2016-10-14 15:08
Analysis date: 2017-01-03 13:53
Analysis date: 2017-01-03 13:53
M-P-5-43 XRayHRQualification
Summary
| Module | Module | M-P-5-43 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 279 | |
| BumpBondingDefects | Bump Bonding Defects | 279 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.82/99.60 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
17 | 99.96 | 99.86 | 99.54 | 0.22 | 21.0 | 67.3 | 17 | 0/0 | 0 |
|
Chip 1
|
A
|
23 | 99.97 | 99.88 | 99.59 | 0.07 | 14.1 | 45.2 | 23 | 0/0 | 0 |
|
Chip 2
|
A
|
14 | 99.96 | 99.86 | 99.54 | 0.07 | 20.9 | 67.1 | 14 | 0/0 | 0 |
|
Chip 3
|
A
|
4 | 99.95 | 99.87 | 99.62 | 0.20 | 33.1 | 106.0 | 4 | 0/0 | 0 |
|
Chip 4
|
A
|
6 | 99.96 | 99.90 | 99.71 | 0.16 | 35.6 | 113.9 | 6 | 0/0 | 0 |
|
Chip 5
|
A
|
7 | 99.95 | 99.90 | 99.73 | 0.14 | 36.2 | 115.8 | 7 | 0/0 | 0 |
|
Chip 6
|
A
|
3 | 99.94 | 99.86 | 99.57 | 0.26 | 36.4 | 116.4 | 3 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.96 | 99.87 | 99.57 | 0.10 | 27.4 | 87.8 | 1 | 0/0 | 0 |
|
Chip 8
|
A
|
3 | 99.96 | 99.79 | 99.25 | 5.81 | 26.6 | 85.2 | 3 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.94 | 99.90 | 99.75 | 0.15 | 31.6 | 101.1 | 1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.97 | 99.89 | 99.64 | 0.14 | 30.9 | 99.0 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.13 | 27.4 | 87.9 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.15 | 28.0 | 89.8 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.95 | 99.88 | 99.65 | 0.14 | 16.9 | 54.3 | 9 | 0/0 | 0 |
|
Chip 14
|
C
|
191 | 99.96 | 99.42 | -1.00 | 0.02 | 7.2 | 23.1 | 191 | 0/0 | 2 |
|
Chip 15
|
A
|
0 | 99.96 | 99.47 | -1.00 | 0.03 | 8.2 | 26.4 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
